The AON DX 60 is not just the AON TLR 60 repurposed without a rim brake track. It is redesigned from the ground up to fit all the aero and performance we have acquired throughout the years from our previous wheelsets. Aero profile paired with wider internal width creates the perfect combo of aero performance and rider comfort.
- Rim profile: 60mm deep profile tubeless ready UD full carbon clincher
- External / Internal width: 27mm / 20mm
- Spokes: Front 24; Rear 24. Sapim CX-Ray. Black
- Hub: 3 pawls, 51 engagement. Center Lock. Enduro bearings
- Interchangeable with Sram XDR driver and Shimano 12S
- Convertible end caps for any standard axle configurations (sold separately)
- External nipple design for easy maintenance
- Hand-built with precision and preinstalled with TLR rim tape
- UCI Approved
TECH SPEC
Rim
- 60mm tubeless ready UD full carbon clincher
- External / Internal width: 27mm / 20mm
Hub
- Front 2 sealed cartridge Enduro bearings
- Rear 4 sealed cartridge Enduro bearings with 7.05 degree engagement. Center Lock. Interchangeable with Sram XDR driver and Shimano 12S
Spoke
- Front (24) Sapim CX-Ray. Black
- Rear (24) Sapim CX-Ray. Black
Nipple
Lacing
- Front 2 cross
- Rear 2 cross
Weight
Rider Weight Limit
